Increased Laboratory Productivity and Efficiency

全球数以千计的用户享受MQC和MQC +范围核磁共振（NMR）分析仪的快速准确的测量。实验室生产率和效率通过MQ-Auto提供额外的提升，该机器人系统延伸了MQC +的工作时间。

MQ-Auto is especially valuable for laboratories which require high throughput and/or high-performance applications which have relatively long measurement times, thus the technician can be relieved for other duties elsewhere.

释放实验室工作人员

需要最小培训的直观软件

Built-in comprehensive safety features

Very few user interventions required

Ask a Question

Request Pricing

Download Brochure

高效的

Requires minimal user input, freeing up laboratory staff for more intensive tasks.

18 or 26 mm tubes

Measures up to 125 samples, 96 or 72 with conditioning dependent on probe size.

Configurable

Different calibrations (and applications) may be loaded to the run list.

Balance option

Compatible with both weighing and non-weighing methods, i.e. with and without a balance.

单一供应商解决方案

MQC +和MQ-Aut均由牛津仪器支持培训的工程师。狗万正网地址

Safety cut-out

Two level security protection to ensure operator safety.

Sample conditioning

选择货架或块requi加热器red by the application.

Flexible

机器人可以暂停，门打开，在跑步期间添加更多样本;可以拆下机架以加载。

Overview and Features

The MQ-Auto system is based around a high-performance robot arm and a range of sample racks and conditioning stations, defined by the application(s), as per the table below. A balance can be incorporated for applications that require samples to be weighed, and an optional barcode reader is also available for sample identification.

样品架	18mm (8ml) sample tubes	26mm (14ml) sample tubes
室温架（最多4个）	每机架最多50 *	Maximum 32 per rack*
Heated blocks (maximum 4)	Maximum 24 per block*	Maximum 18 per block*

*必须为调整样本和初始化程序保留三个位置

Safety and Operation

操作员安全当然是任何电气或机械安装至关重要的，因此MQ-Auto内置了全面的安全功能。机器人臂本身是一个所谓的“协作机器人”，设计用于在其路径中遇到任何障碍物（例如人肢）时自动停止。除此之外，如果门打开，整个自动进样器安装互锁以关闭机器人臂的透明机箱。这种两级安全保护可确保系统可以安全地安全运行。

The MQ-Auto is controlled by software running on either the Windows-10 internal computer of the MQC+ instrument or on an external PC. The software allows samples to be run against different calibrations, and also allows operation to be paused mid-run for additional samples to be added. Optional barcodes can be attached to sample tubes to identify the sample and to store the tare weight of the tube for measurements that require weighing.
